Power Your Network with Durable & Weather-Resistant ABC Cables
ONE-STOP SOLUTIONS FOR WIRES & CABLES - HENAN UME CABLE CO., LTD
Over 30 years of Wires and Cables manufacture experience and Export to over 50 countries.
Applications
Used as bare overhead conductor for primary and secondary distribution. Designed for utilizing a high-strength aluminum-alloy to achieve a high strength-to-weight ratio; affords good sag characteristics.
Standards
- Covered Aluminum Cables-15Kv
- Covered Aluminum Cables-25Kv
- Covered Aluminum Cables-35Kv
Product Parameters
Covered Aluminum Cables-15Kv
| Cross section [mm²] |
No. of wires |
Conductor diam. [mm] |
Overall Diameter [mm] |
Minimum breaking load [kgf] |
Approx. weight [kg/km] |
Max. DC-resistance at 20°C [Ohm/km] |
Ampacity 90°C [A] |
| 35 | 7 | 7.1 | 13.6 | 464 | 190 | 0.868 | 187 |
| 50 | 7 | 8.2 | 14.7 | 663 | 235 | 0.641 | 225 |
| 70 | 19 | 9.7 | 16.2 | 928 | 315 | 0.443 | 282 |
| 95 | 19 | 11.5 | 18 | 1259 | 400 | 0.320 | 345 |
| 120 | 19 | 12.9 | 19.4 | 1591 | 500 | 0.253 | 401 |
| 150 | 19 | 14.2 | 20.7 | 1988 | 580 | 0.206 | 456 |
| 185 | 37 | 16.2 | 22.6 | 2452 | 695 | 0.164 | 525 |
| 240 | 37 | 18.4 | 24.9 | 3182 | 875 | 0.125 | 625 |
| 300 | 37 | 20.7 | 27.1 | 3977 | 1070 | 0.100 | 721 |
Covered Aluminum Cables-25Kv
| Cross section [mm²] |
No. of wires |
Conductor dia. [mm] |
Overall Diameter [mm] |
Minimum breaking load [kgf] |
Approx. weight [kg/km] |
Max. DC-resistance at 20°C [Ohm/km] |
Ampacity 90°C [A] |
| 35 | 7 | 7.1 | 15.7 | 464 | 235 | 0.868 | 186 |
| 50 | 7 | 8.2 | 16.8 | 663 | 305 | 0.641 | 224 |
| 70 | 19 | 9.7 | 18.3 | 928 | 370 | 0.443 | 280 |
| 95 | 19 | 11.5 | 20.1 | 1259 | 460 | 0.32 | 343 |
| 120 | 19 | 12.9 | 21.5 | 1591 | 560 | 0.253 | 397 |
| 150 | 19 | 14.2 | 22.8 | 1988 | 650 | 0.206 | 450 |
| 185 | 37 | 16.2 | 24.8 | 2452 | 770 | 0.164 | 519 |
| 240 | 37 | 18.4 | 27 | 3182 | 960 | 0.125 | 617 |
| 300 | 37 | 20.7 | 29.3 | 3977 | 1155 | 0.1 | 712 |
Covered Aluminum Cables-35Kv
| Cross section [mm²] |
No. of wires |
Conductor dia. [mm] |
Overall Diameter [mm] |
Minimum breaking load [kgf] |
Approx. weight [kg/km] |
Max. DC-resistance at 20°C [Ohm/km] |
Ampacity 90°C [A] |
| 70 | 19 | 9.7 | 25.7 | 928 | 620 | 0.443 | 270 |
| 95 | 19 | 11.5 | 27.5 | 1259 | 732 | 0.32 | 329 |
| 120 | 19 | 12.9 | 28.9 | 1591 | 830 | 0.253 | 381 |
| 150 | 19 | 14.2 | 30.2 | 1988 | 937 | 0.206 | 432 |
| 185 | 37 | 16.2 | 32.2 | 2452 | 1083 | 0.164 | 497 |
| 240 | 37 | 18.4 | 34.4 | 3182 | 1290 | 0.125 | 589 |
| 300 | 37 | 20.7 | 36.7 | 3977 | 1502 | 0.1 | 674 |
Quality Testing
HENAN UME CABLE CO., LTD has a strict quality control policy in every step from the order to After-sales service!
- Raw material inspection and test
- Production process test
- Unqualified product control
- Regular test and examination
- Finished product inspection
Certifications
UME CABLE has completed several third-party product certifications to ensure our customers that all of the wire and cable purchased and installed in your projects, will fully and consistently meet all criteria of the required production and performance standards.
ISO9001
ISO14001
ISO45001
CE
SGS
TUV
Packaging & Shipping
Customer Visit
Company Profile
UME CABLE is one of the leading companies in the production and distribution of cables and wires in China. As a manufacturer, we have supplied quality products to more than 50 countries. Our mission is to offer our customers the best quality cable and wire products at the most competitive price, to extend and zoom the business success of our partners, to make power reach where it is needed, to optimize the running utility grids, and ultimately, to power the world. Our version is to be the most customer-centric cable and wire company with our solid technology, enthusiastic services, and robust products.
UME Cable was founded in 1994, located in Zhengzhou Gongyi Huiguo Town, and occupies a total area of more than 200,000 square meters, with a building area of 20,000 square meters. The real capital assets are more than USD 6 million, with a total of 230 staff members, 35 of which are professional and technical experts. The land of our factory and employees numbers might not be the top scale of industry, but our highly automatic facilities and elite employees are the best in the industry will guarantee you a high yield rate achieved by strict cost and quality control, this is why we could quote better quality with the most competitive price within the market.
Frequently Asked Questions
Q1: Are you a manufacturer?
Yes, we are the manufacturer.
Q2: What are your main products?
Our products range as follows:
- Electrical wire/PVC Building Wires.
- PVC/XLPE insulated Power Cables up to 110kv.
- Overhead Aerial Bundle Cable/ABC Cables.
- Bare Conductors, like AAC, AAAC, ACSR, ACAR, ASCR/AW, and so on.
- Steel wire/strand-like EHS, GSW and ACS(Aluminum Clad Steel), CCS(Copper Clad Steel).
- Rubber Cables, Mining Cables, Welding Cable, and Control Cables.
- Concentric Cables with Copper/Aluminum/Aluminum Alloy 8000s' Conductor.
Q3: Do you provide samples? Is it free or extra?
Yes, we could offer the samples for free.
Q4: Is the quality of your products guaranteed?
We have passed ISO9001, ISO14001, ISO45001, and all our products have CE certificates.
Q5: Which markets do you involve mainly in?
Our products have been exported mainly to Africa, the Middle East, Southeast Asia, South America, Central America, North America, Europe, Australia, etc.
Q6: What is your payment term?
T/T or L/C
Q7: What about the delivery time?
Generally, it is 3-7 days if the goods are in stock. Or it is 7-30 days if the goods are not in stock, it is according to quantity.
